Establishing an Industry Benchmark
With significant improvements, these models go well beyond simply meeting emission requirements and will establish a new benchmark in the industry.
DX140LC-7
• More power: +15%
• More pull: +34% (+5% for 140)
• More torque: +12%
• Faster: +6% (only for 140)
• Up to 17.5% reduction of fuel consumption
• Noise level redued by -1 dB(a)
| DX140LC-5 | Specifications |
| Operating weight | 14,100 – 14,500 kg |
| Engine | Doosan DL06K |
| Engine power | 138 kW / 109 HP at 1900 RPM |
| Main pumps max flow | 2 x 219 l/min |
| Number of cylinders | 6 |
| Travel speed | 3.2 / 5.6 km/h |
| Maximum traction force | 16.6 - 28.5 t |
| Buckets | 0.24 - 0.76 m³ |
| Sound level (internal / external) | 70 dB(A) (ISO 6396) |
| Overall width | 3,200 mm |
| Overall height (Std Front) | 3,555 mm |
| Overall length (Std Front) | 10,100 mm |
| Tail swing radius | 2,995 mm |
| Bucket digging force | 265.7 kN |
| Arm digging force (Std Front) | 166.7 / 175.5 kN |
| Max. digging reach (Std Front) | 10,605 mm |
| Max. digging depth (Std Front) | 7,315 mm |
| Max. digging height (Std Front) | 7,170 mm |
