A new benchmark in the industry, in terms of total cost of owner ship for your customers, by offering higher performance, reduced fuel consumption,ease of operation and higher uptime.
DX160LC-7
| DX160LC-7 | Specifications |
| Operating weight | 14,400 kg |
| Engine | Doosan DL06 |
| Engine power | 82kW / 109 HP at 1850 RPM |
| Main pumps max flow | 2 x 114 l/min |
| Number of cylinders | 6 |
| Travel speed | 5.0 / 3.0 km/h |
| Maximum traction force | 6.7 - 12.4 t |
| Buckets | 0.24 - 0.76 m³ |
| Sound level (internal / external) | 70 dB(A) (ISO 6396) |
| Overall width | 2,590 mm |
| Overall height (Std Front) | 2,773 mm |
| Overall length (Std Front) | 7,680 mm |
| Tail swing radius | 2,220 mm |
| Bucket digging force | 102.9 / 108.8 kN |
| Arm digging force (Std Front) | 54.9 / 58.8 kN |
| Max. digging reach (Std Front) | 8,285 mm |
| Max. digging depth (Std Front) | 5,635 mm |
| Max. digging height (Std Front) | 8,660 mm |
