The DX235LCR-5 is fitted with a new and much larger cab. The features offered as standard in the cab are among the best in the market and include: outstanding comfort, ease-of-operation thanks to extra ergonomics, and super controllability.
DX235LCR-7
| DX235LCR-5 | Specifications |
| Operating weight | 24320 kg |
| Engine | Doosan DL06P |
| Engine power | 141 kW (189 HP) @ 1900 rpm (SAE J1995) |
| Main pumps max flow | 2 x 222 l/m |
| Number of cylinders | 6 |
| Travel speed | 3.2 / 5.8 km/h |
| Maximum traction | 29.2 / 15.8 ton |
| Buckets | 0.51 – 1.32 m³ |
| Sound level (internal / external) | 74 dB(A) - 103 dB(A) |
| Overall height (Std Front) | 2980 mm |
| Overall length (Std Front) | 8975 mm |
| Tail swing radius | 2310 mm |
| Bucket digging force | 16.0 t |
| Arm digging force (Std Front) | 11.1 t |
| Max. digging reach (Std Front) | 9820 mm |
| Max. digging depth (Std Front) | 6670 mm |
| Max. digging height (Std Front) | 10795 mm |
