Mecalac/Terex 3 tonne site dumpers are designed to be easy to operate and maintain with unrivalled strength and reliability, providing increased uptime at a lower cost. With class leading skip capacities, strong chassis fabrications and user friendly controls, these models are in high demand across the widest range of applications.
Models Variants: TA3/ TA3S/ TA3H/TA3SH
TA3
Designed for the small to medium job site the TA3 Range, consisting of the TA3, TA3S, TA3H, TA3SH and TA3.5SH offers versatility for your material movement.
With a skip payload of 3000kg / 3500kg, choose between straight tip skip for bulk material movement or the 180-degree power swivel skip which allows precision placement of loads to either side of the machine.
The optional hydrostatic transmission delivers smooth and uninterrupted power for the operator. Simple user-friendly controls help all operators adapt quickly.
Model Variants:
| Model | TA3 | TA3S | TA3H | TA3SH |
| PERFORMANCE: | ||||
| Payload (Kg) | 3000 | 3000 | 3000 | 3000 |
| Unladen Weight (Kg) | 2280 | 2330 | 2290 | 2340 |
| Tipping Type | Forward Tip | Swivel Tip | Forward Tip | Swivel Tip |
| Engine | Kubota V2203M | Kubota V2203M | Kubota V2203M | Kubota V2203M |
| Gross Power – kW (hp) | 32.4 (43.5) | 32.4 (43.5) | 32.4 (43.5) | 32.4 (43.5) |
| Maximum Torque (Nm) | 145Nm | 145Nm | 145Nm | 145Nm |
| Aspiration | Naturally Aspirated | Naturally Aspirated | Naturally Aspirated | Naturally Aspirated |
| TRANSMISSION/DRIVE: | ||||
| Transmission Type | Manual Gearbox | Manual Gearbox | Hydrostatic Motor | Hydrostatic Motor |
| Drive | 3 Forward / 1 Reverse | 3 Forward / 1 Reverse | 2 / 2 (High & Low Range) Hydrostatic | 2 / 2 (High & Low Range) Hydrostatic |
| Tyre Size | 295/80 x 15.3 x 10 ply | 295/80 x 15.3 x 10 ply | 295/80 x 15.3 x 10 ply | 295/80 x 15.3 x 10 ply |
| DIMENSIONS: | ||||
| Total Length (mm) | 3725 | 3952 | 3725 | 3952 |
| Total Width (Max) (mm) | 1957 | 1846 | 1957 | 1846 |
| Wheelbase (mm) | 1937 | 1937 | 1937 | 1937 |
| Ground Clearance (mm) | 279 | 279 | 279 | 279 |
| Height to Front Lip of Skip (untipped) (mm) | 1371 | 1467 | 1371 | 1467 |
| Height to Front Lip of Skip (tipped) (mm) | 208 | 762 | 208 | 762 |
